Rexton Steel & Alloys is one of the largest exporter, manufacturer and supplier of Nickel Alloy 201 Flanges in India.These Alloy 201 Flanges are in fact seamless for applications where greater strength and improved corrosion resistance is essential. Because of soaring tensile strength and durable construction, these UNS N02201 Flanges are widely used in machined components, pump shafts, fasteners,valves andhandles. Nickel 201 Flangesare being manufactured by using superior quality ofmaterials and in that manner it makes sure to givean excellenttoughness.
As an acclaimed enterprise of the industry, Rexton is involved in offering a vast array of Nickel Alloy Flanges as a manufacturer, exporter, stockiest and supplier to our domestic and global clients.
Further, manufactured by using finest quality of raw materials, these flangesare extensively used in construction and a number of other related industries. Our WNR 2.4068 Flangesare accessible to our valuable customers in different range of diameters, wall thicknesses and sizes at quite affordable rates.
Our AS Pipe Flanges are available in customized length, sizes and shapes to our esteemed clients at market leading prices.
| Standards | ASTM, ASME Flanges, ANSI Flanges, DIN Flanges, EN Flanges, BS Flanges etc. |
|---|---|
| Specification | ASTM B 564 / ASME SB 564 |
| Size | ½” NB – 48″ NB |
| Class | 150#, 300#, 600#, 900#, 1500#, 2500# |
| Pressure | DIN PN6, PN10, PN16, PN25, PN40, PN64, PN100, PN160, etc |
| Certification | IBR & NON IBR |
| Werkstoff Nr | Nickel Alloy 200 (UNS No. N02200)/2.4060, 2.4066 Nickel Alloy 201 (UNS No. N02201)/2.4060, 2.4066 |
|
Nickel : Grade: Nickel 200, Nickel 201 |
| Grade | Ni | Fe | C | Mn | Si | Cu | Mg | Ti | S |
| Nickel 201 | 99.0 min | 0.4 max | 0.02 max | 0.35 max | 0.2 max | 0.25 max | 0.15 max | 0.1 max | 0.01 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| Threaded Flanges |  |
Threaded Flanges are also known as screwed flange, and it is having a thread inside the flange bore which fits on the pipe with matching male thread on the pipe. |
|---|---|---|
| Socket-Weld Flanges |  |
Socket-Weld Flanges has a female socket in which pipe is fitted. Fillet welding is done from outside on the pipe. |
| Slip-On Flanges |  |
Slip-On flange has a hole with matching outside diameter of pipe from which pipe can pass. The flange is placed on pipe and fillet welded from both inside and outside. |
| Lap Joint Flanges |  |
Lap flange is having two components, a stub end, and a loose backing flange. Stub end is butt welded to the pipe and Backing flange freely move over the pipe. |
| Weld Neck Flanges |  |
Weld neck flange are most widely used flanged in process piping. It gives the highest level of joint integrity due to Butt-welded with a pipe. |
| Blind Flanges |  |
The blind flange is a blank disc with bolt hole. These types of flanges are used with another type of flange to isolate the piping system |
| Screwed Flange |  |
3Screwed Flange is used to connect other components in non-critical applications, low-pressure in which no welding is required. |
| Reducing Flange |  |
A reducing flange consists of a flange with one specific diameter having different bore and smaller diameter. It s used to change the diameters in piping system. |
| Forged Flange |  |
They are designed by using corrosion free substance and using an advanced technology. Our team of experts identify each and every product to ensure the best quality and flawless of these products available at suitable rates |
| Orifice Flange |  |
Orifice Flange helps to measure the flow of liquids and gases using orifice meters located on the outside diameter of the flanges. The main purpose of the orifice flange identifies the flow rate of either liquid or gas in the pipeline system. |
| Spectacle Flange |  |
A spectacle flange is a specialty flange made of two metal discs attached in the middle by a small section of steel. Spectable flanges get their name because they look like a pair of reading glasses, or spectacles. |
|
Stainless Steel : Grade: 304, 304L, 304H, 309, 309S, 316, 316L, 316H, 310, 310S, 317, 317L, 321, 347, 904L Carbon Steel : Grade: WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70 Alloy Steel: Grade : WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91 Monel : Grade: Monel 400, Monel K500, Monel R-405 Inconel : Grade: Inconel 600, Inconel 601, Inconel 625, Inconel 718 Incoloy : Grade: Incoloy 800, Incoloy 800H, Incoloy 800HT Hastalloy : Grade: Hastalloy B2, Hastalloy B3, Hastalloy C22, Hastalloy C276, Hastalloy X Titanium : Grade: Gr1, Gr2, Gr3, Gr5, Gr7, Gr11 Duplex Steel: Grade: UNS F44, F45, F51, F53, F55, F60, F61 |
